Asus m3a79-t deluxe /amd790fx

Asus M3A79-T Deluxe

• CPU
AMD Socket AM2+ / AM2 Processors
for AMD Phenom FX / Phenom / Athlon / Sempron processors
AMD Cool 'n' Quiet Technology
Supports CPU up to 140W

• System bus
Up to 5200 MT/s HyperTransport 3.0 interface for AM2+ CPU
2000 / 1600 MT/s for AM2 CPU

• Chipset
AMD 790FX/SB750

• Memory
4 x240-pin DIMM, Max. 16 GB, DDR2 1066/800/667 Memory
Dual Channel memory architecture

• VGA
-

• Expansion Slots
Supports ATI CrossFireX graphics cards; up to Quad CrossFireX
4 x PCIe 2.0 x16 slots with ATI CrossFireX support (@ dual x16, triple x16 / x8 / x8, or quad x8 modes)
2 x PCI 2.2

• Connectors
3 x USB connectors support additional 6 USB ports
1 x Floppy disk drive connector
1 x IDE connector
1 x COM connector
6 x SATA connectors
1 x CPU Fan connector
2 x Chassis Fan connectors
1 x Power Fan connector
1 x IEEE1394a connector
Front panel audio connector
1 x S/PDIF Out header
Chassis Intrusion connector
CD audio in
24-pin ATX Power connector
System Panel (Q-Connector)
8-pin ATX 12V Power connector
Power on Switch
Reset Switch

• Audio
ADI AD2000B 8 -Channel High Definition Audio CODEC
- Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking
- Coaxial / Optical S/PDIF Out ports at back I/O
- ASUS AI Audio 2
- ASUS Noise Filtering

• LAN
Marvell 88E8056 Gigabit LAN controller featuring AI NET 2

• IEEE 1394
LSI L-FW3227 controller supports 2 x 1394a ports (1 at mid-board; 1 at back panel)

• Rear Panel I/O Ports
1 x PS/2 Keyboard / Mouse combo port
1 x Optical + 1 x Coaxial S/PDIF Out ports
1 x External SATA port
1 x IEEE1394a port
1 x LAN (RJ45) port
6 x USB 2.0/1.1 ports
8-channel Audio I/O ports

• BIOS
8 Mb Flash ROM, AMI BIOS, PnP, DMI 2.0, SM BIOS 2.5, ACPI 2.0a, ASUS EZ Flash 2, ASUS CrashFree BIOS 2

• Form Factor
ATX

• Dimensions
30.5 cm x 24.4 cm

• Package
Box

Гаранция 36 месеца
