Камерата DCS-1130 е много добро и сигурно решение за домашни или офис потребители имащи нужда от наблюдение на определени обекти в реално време.
Камерата позволява не само наблюдение на картина, но и приемане на звук/аудио от обектите.
DCS-1130 поддържа Уеб базиран достъп за отдалечено управление, което ви позволява да инсталирате камерта в къщи или в офиса, след което да наблюдавате обектите от всякъде през компютър имащ инсталиран Internet Explorer и достъп до мрежата.
|
Specifications
|
Camera Specifications
|
•
|
Sensor: ¼” CMOS
|
•
|
Lens: 5.01mm, F2.8
|
•
|
Minimum Illumination: 1.0 Lux @ F2.8
|
•
|
3A Control: AGC, AWB, AES
|
•
|
Electronic Shutter: 1/60(1-50) ~ 1/15,000 Sec
|
•
|
16x Digital Zoom
|
|
Audio
|
•
|
Built-in Omni-directional Microphone
|
•
|
Frequency: 50 ~ 16000Hz
|
•
|
S/N Ratio: 6mm, -40db + 3db
|
|
Video Formats Supported
|
•
|
MPEG-4 and MJPEG (Simultaneous Dual Format Compression)
|
•
|
JPEG for Still Images
|
|
Display type
|
|
Multi-Profile
|
•
|
Supports 4 profiles simultaneously
|
|
Features
|
•
|
Adjustable image size and quality
|
•
|
Time stamp and text overlay
|
•
|
Three configurable motion detection windows
|
•
|
Flip and Mirror
|
|
Resolution
|
•
|
Up to 30 frames at 640x480
|
•
|
Up to 30 frames at 320x240
|
•
|
Up to 30 frames at 160x120
|
|
Connectivity
|
•
|
Wireless (Draft 802.11n) Network (Backward compatible with 802.11g)
|
•
|
Wired (10/100 Fast Ethernet) Network
|
|
Security
|
•
|
Password Authentication
|
|
LEDs
|
|
Networking Protocols
|
•
|
IPV4, ARP, TCP, UDP, ICMP
|
•
|
DHCP Client
|
•
|
NTP Client (D-Link)
|
•
|
DNS Client
|
•
|
DDNS Client (D-Link)
|
•
|
SMTP Client
|
•
|
FTP Client
|
•
|
HTTP Server
|
•
|
Samba Client
|
•
|
PPPoE
|
•
|
UPnP Port Forwarding
|
•
|
RTP
|
•
|
RTSP
|
•
|
RTCP
|
•
|
3GPP
|
|
Certifications
|
•
|
FCC Class B
|
•
|
IC
|
•
|
CE
|
•
|
C-Tick
|
|
Power
|
•
|
External Power Supply: 5VDC, 2.5A
|
•
|
Consumption: 4 Watts Max
|
|
Temperature
|
•
|
Operating: 32°F to 104°F (0°C to 40°C)
|
•
|
Storage: -4°F to 158°F (-20°C to 70°C)
|
|
Operating Humidity
|
•
|
20%-80% RH Non-condensing
|
|
Minimum System Requirements
|
•
|
Wireless (Draft 802.11n) Network
|
•
|
PC with:
•
|
1.3 GHz Processor
|
•
|
128MB Memory
|
•
|
Windows Vista® or Windows® XP SP2
|
•
|
Internet Explorer® v6 and later
|
|
|
Multiple Camera Operation Requires
|
•
|
Wireless (Draft 802.11n) Network
|
•
|
PC with:
•
|
2.4GHzProcessor
|
•
|
512MB Memory
|
•
|
32MB Video Card
|
•
|
Windows Vista® or Windows® XP SP2
|
•
|
Internet Explorer® v6 and later
|
|
|
Package Contents
|
•
|
Wireless N Network Camera
|
•
|
CAT5 Ethernet Cable
|
•
|
2 Detachable Antennas
|
•
|
Power Adapter
|
•
|
Camera Base and Mounting Kit
|
•
|
Quick Installation Guide
|
•
|
CD-ROM** with:
•
|
Software
|
•
|
Product Documentation
|
|
|
Dimensions (L x W x H)
|
•
|
Item: 1.5” x 3.2” x 4.7” (38 mm x 81mm x 119mm)
|
•
|
Packaging: 1.6” x 10.8” x 8.2” (41mm x 274mm x 208mm)
|
|
Weight
|
•
|
Item: 0.5 lbs (226.8 g)
|
•
|
Packaging: 2.0 lbs (907.2g)
|
|
